6. Using the WAPT Server APIs

Note

This documentation does not describe all the available APIs, it will however concentrate on the most useful ones.

All available API URLs may be found in /opt/wapt/waptserver/server.py.

URLs are formed by calling the proper command from the WAPT Server, ex: https://srvwapt/command_path.

Hint

This documentation contains examples using Python code or curl.

Warning

Since version 2.5, most API URLs are protected with SSL client certificates. You will have to modify your scripts (cf. examples below).

6.1. API V1

6.1.1. /api/v1/hosts

  • Get registration data of one or several hosts.

    # Args:
    #     has_errors (0/1): filter out hosts with packages errors
    #     need_upgrade (0/1): filter out hosts with outdated packages
    #     groups (csvlist of packages): hosts with packages
    #     columns (csvlist of columns):
    #     uuid (csvlist of uuid): <uuid1[,uuid2,...]>): filter based on uuid
    #     filter (csvlist of field):regular expression: filter based on attributes
    #     not_filter (0,1):
    #     limit (int): 1000
    #     trusted_certs_sha256 (csvlist): filter out hosts based on their trusted package certs

    # Returns:
    #     result (dict): {'records':[],'files':[]}
    #     query:
    #       uuid=<uuid>
    #     or
    #       filter=<csvlist of fields>:regular expression
    # """

  • List all hosts using the following parameters:

    • reachable;

    • computer_fqdn ==> computer_name;

    • connected_ips;

    • mac_addresses.

    This example shows a request with parameters:

    cert_path = (r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt',r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem')
    advanced_hosts_wapt = wgets('https://%s:%s@%s/api/v1/hosts?columns=reachable,computer_fqdn,connected_ips,mac_addresses&limit=10000' % (wapt_user,wapt_password,wapt_url),verify_cert=False,cert=cert_path)
    parsed = json.loads(advanced_hosts_wapt)
    print(json.dumps(parsed, indent=1, sort_keys=True))


    This example is a global request:

    cert_path = (r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt',r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem')
    hosts_wapt = wgets('https://%s:%s@%s/api/v1/hosts' % (wapt_user,wapt_password,wapt_url),verify_cert=False,cert=cert_path)
    parsed = json.loads(hosts_wapt)
    print(json.dumps(parsed, indent=1, sort_keys=True))


    Hint

    This is the same exemple with a simple html request:

    https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v1/hosts


    This one just show request with reachable status, the computer name, its connected ips and its mac addresses. The display limit is 10000.

    https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v1/hosts?columns=reachable,computer_fqdn,connected_ips,mac_addresses&limit=10000


6.1.2. /api/v1/groups

  • Get all group packages. Group is found with section group in the package:

    cert_path = (r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt',r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem')
    group_wapt = wgets('https://%s:%s@%s/api/v1/groups' % (wapt_user,wapt_password,wapt_url),verify_cert=False,cert=cert_path)
    parsed = json.loads(group_wapt)
    print(json.dumps(parsed, indent=1, sort_keys=True))


    Hint

    This is the same exemple with a simple html request:

    https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v1/groups


6.1.3. /api/v1/host_data

6.1.3.1. dmi

  • Get DMI info for a host:

Note

# # Get additional data for a host # query: # uuid=<uuid> # field=packages, dmi or softwares

Note

dmi is not the only available option. You can also lookup information using installed_packages, wsusupdates ou installed_softwares.

cert_path = (r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt',r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem')
dmi_host_data_wapt = wgets('https://%s:%s@%s/api/v1/host_data?uuid=UUID&field=dmi' % (wapt_user,wapt_password,wapt_url),verify_cert=False,cert=cert_path)
#print(dmi_host_data_wapt)
parsed = json.loads(dmi_host_data_wapt)
print(json.dumps(parsed, indent=1, sort_keys=True))

Hint

This is the same exemple with a simple html request:

https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v1/host_data?uuid=14F620FF-DE70-9E5B-996A-B597E8F9B4AD&field=dmi

6.1.3.2. installed_packages

Option installed_packages will list all packages installed on a specific host.

cert_path = (r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt',r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem')
install_packages_data_wapt = wgets('https://%s:%s@%s/api/v1/host_data?uuid=UUID&field=installed_packages' % (wapt_user,wapt_password,wapt_url),verify_cert=False,cert=cert_path)
parsed = json.loads(install_packages_data_wapt)
print(json.dumps(parsed, indent=1, sort_keys=True))

Hint

This is the same exemple with a simple html request:

https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v1/host_data?uuid=14F620FF-DE70-9E5B-996A-B597E8F9B4AD&field=installed_packages

6.1.3.3. installed_softwares

Option installed_softwares will list all softwares installed on a specific host.

cert_path = (r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt',r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem')
install_softwares_data_wapt = wgets('https://%s:%s@%s/api/v1/host_data?uuid=UUID&field=installed_softwares' % (wapt_user,wapt_password,wapt_url),verify_cert=False,cert=cert_path)
#print(install_softwares_data_wapt)
parsed = json.loads(install_softwares_data_wapt)
print(json.dumps(parsed, indent=1, sort_keys=True))

Hint

This is the same exemple with a simple html request:

https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v1/host_data?uuid=14F620FF-DE70-9E5B-996A-B597E8F9B4AD&field=installed_softwares

6.1.3.4. wsusupdates

Option wsusupdates will list all Windows Updates installed on a specific host.

cert_path = (r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt',r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem')
wsusupdates_data_wapt = wgets('https://%s:%s@%s/api/v1/host_data?uuid=UUID&field=wsusupdates' % (wapt_user,wapt_password,wapt_url),verify_cert=False,cert=cert_path)
#print(wsusupdates_data_wapt)
parsed = json.loads(wsusupdates_data_wapt)
print(json.dumps(parsed, indent=1, sort_keys=True))

Hint

This is the same exemple with a simple html request:

https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v1/host_data?uuid=14F620FF-DE70-9E5B-996A-B597E8F9B4AD&field=wsusupdates

6.1.4. /api/v1/usage_statistics

Get usage statistics from the WAPT Server.

Hint

This API is useful if you have several WAPT Servers and you want to know how many hosts are there.

cert_path = (r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt',r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem')
usage_statistics_wapt =wgets('https://%s:%s@%s/api/v1/usage_statistics' % (wapt_user,wapt_password,wapt_url),verify_cert=False,cert=cert_path)
#print(usage_statistics_wapt)
parsed = json.loads(usage_statistics_wapt)
print(json.dumps(parsed, indent=1, sort_keys=True))

Hint

This is the same exemple with a simple html request:

https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v1/usage_statistics

6.2. API V2

6.2.1. /api/v2/waptagent_version

Display waptagent.exe version.

waptagent_version = wgets('https://%s:%s@%s/api/v2/waptagent_version' % (wapt_user,wapt_password,wapt_url))
parsed = json.loads(waptagent_version)
print(json.dumps(parsed, indent=1, sort_keys=True))

Hint

This is the same exemple with a simple html request:

https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v2/waptagent_version

6.3. API V3

6.3.1. /api/v3/packages

List packages on the repository, retrieve the control files of WAPT packages.

cert_path = (r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt',r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem')
packages_wapt = wgets('https://%s:%s@%s/api/v3/packages' % (wapt_user,wapt_password,wapt_url),verify_cert=False,cert=cert_path)
parsed = json.loads(packages_wapt)
print(json.dumps(parsed, indent=1, sort_keys=True))

Hint

This is the same exemple with a simple html request:

https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v3/packages

6.3.2. /api/v3/known_packages

List all packages with last signed_on information.

cert_path = (r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt',r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem')
known_packages_wapt = wgets('https://%s:%s@%s/api/v3/known_packages' % (wapt_user,wapt_password,wapt_url),verify_cert=False,cert=cert_path)
parsed = json.loads(known_packages_wapt)
print(json.dumps(parsed, indent=1, sort_keys=True))

Hint

This is the same exemple with a simple html request:

https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v3/known_packages

6.3.3. /api/v3/trigger_cancel_task

Cancel a running task.

cert_path = (r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt',r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem')
trigger_cancel_task = wgets('https://%s:%s@%s/api/v3/trigger_cancel_task' % (wapt_user,wapt_password,wapt_url),verify_cert=False,cert=cert_path)
parsed = json.loads(trigger_cancel_task)
print(json.dumps(parsed, indent=1, sort_keys=True))

6.3.4. /api/v3/get_ad_ou

List OU seen by hosts and displayed in the WAPT Console.

cert_path = (r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt',r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem')
get_ad_ou = wgets('https://%s:%s@%s/api/v3/get_ad_ou' % (wapt_user,wapt_password,wapt_url),verify_cert=False,cert=cert_path)
parsed = json.loads(get_ad_ou)
print(json.dumps(parsed, indent=1, sort_keys=True))

Hint

This is the same exemple with a simple html request:

https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v3/get_ad_ou

6.3.5. /api/v3/get_ad_sites

List Active Directory sites.

cert_path = (r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt',r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem')
get_ad_sites = wgets('https://%s:%s@%s/api/v3/get_ad_sites' % (wapt_user,wapt_password,wapt_url),verify_cert=False,cert=cert_path)
parsed = json.loads(get_ad_sites)
print(json.dumps(parsed, indent=1, sort_keys=True))

Hint

This is the same exemple with a simple html request:

https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v3/get_ad_sites

6.3.6. /api/v3/hosts_for_package

List hosts with a specific package installed.

cert_path = (r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt',r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem')
hosts_for_package = wgets('https://%s:%s@%s/api/v3/hosts_for_package?package=PACKAGE' % (wapt_user,wapt_password,wapt_url),verify_cert=False,cert=cert_path)
parsed = json.loads(hosts_for_package)
print(json.dumps(parsed, indent=1, sort_keys=True))

Hint

This is the same exemple with a simple html request:

https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v3/hosts_for_package?package=demo-namepackage

6.3.7. /api/v3/host_tasks_status

List tasks on a particular host.

cert_path = (r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt',r'C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem')
host_tasks_status = wgets('https://%s:%s@%s/api/v3/host_tasks_status?uuid=UUID' % (wapt_user,wapt_password,wapt_url),verify_cert=False,cert=cert_path)
parsed = json.loads(host_tasks_status)
print(json.dumps(parsed, indent=1, sort_keys=True))

Hint

This is the same exemple with a simple html request:

https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v3/host_tasks_status?uuid=14F620FF-DE70-9E5B-996A-B597E8F9B4AD

Attention

Next API are with POST method.

6.3.8. /api/v3/upload_packages

Todo

Tests

6.3.9. /api/v3/upload_hosts

Todo

Tests

6.3.10. /api/v3/change_password

Change the Admininistrator password [only this account]. The request is a python dictionnary {} with keys:

  • user;

  • old_password;

  • new_password.

curl --cert "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt" --key "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem" --insecure -X POST --data-raw '{"user":"USER","password":"old_password","new_password":"new_password"}' -H "Content-Type: application/json" "https://user:old_password@srvwapt/api/v3/change_password"

6.3.11. /api/v3/login

Initialize a connection to the WAPT Server.

curl --insecure -X POST --data-raw '{"user":"admin","password":"MYPASSWORD"}' -H "Content-Type: application/json" "https://srvwapt.mydomain.lan/api/v3/login"

{"msg": "Authentication OK", "result": {"edition": "enterprise", "hosts_count": 6, "version": "1.7.4", "server_domain": "mydomain.lan", "server_uuid": "32464dd6-c261-11e8-87be-cee799b43a00"}, "success": true, "request_time": 0.03377699851989746}

Hint

We can make a connection by html form then POST: https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v3/get_ad_sites

6.3.12. /api/v3/packages_delete

Delete package with a precise version. The request is a python list []. A list of packages may be given, separated by commas ,.

Example:

curl --cert "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt" --key "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem" --insecure -X POST --data-raw '["demo-libreoffice-stable_5.4.6.2-3_all.wapt"]' -H "Content-Type: application/json" "https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v3/packages_delete"

6.3.13. /api/v3/reset_hosts_sid

Reinitialize all host connections.

For the POST method, the syntax is: --data-raw a dictionnary list with uuids as keys and the UUIDs of the hosts as values.

curl --cert "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt" --key "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem" --insecure -X POST --data-raw '{"uuids":["UUID"]}' -H "Content-Type: application/json" "https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v3/reset_hosts_sid"

{"msg": "Hosts connection reset launched for 1 host(s)", "result": {}, "success": true, "request_time": null}

Hint

If you want several hosts:

curl --cert "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt" --key "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem" --insecure -X POST --data-raw '{"uuids":["UUID#1","UUID#2"]}' -H "Content-Type: application/json" "https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v3/reset_hosts_sid"

{"msg": "Hosts connection reset launched for 2 host(s)", "result": {}, "success": true, "request_time": null}

6.3.14. /api/v3/trigger_wakeonlan

If hosts are WakeOnLan enabled, this API is useful.

Syntax is --data-raw: a dictionnary with key uuids and a list of host uuids.

curl --cert "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt" --key "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem" --insecure -X POST --data-raw '{"uuids":["UUID"]}' -H "Content-Type: application/json" "https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v3/trigger_wakeonlan"

{"msg": "Wakeonlan packets sent to 1 machines.", "result": [{"computer_fqdn": "computer_fqdn", "mac_addresses": ["mac_addresses"], "uuid": "UUID"}], "success": true, "request_time": null}

Hint

If you want several hosts:

curl --cert "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt" --key "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem" --insecure -X POST --data-raw '{"uuids":["UUID#1","UUID#2"]}' -H "Content-Type: application/json" "https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v3/trigger_wakeonlan"

{"msg": "Wakeonlan packets sent to 2 machines.", "result": [{"computer_fqdn": "computer_fqdn#1", "mac_addresses": ["mac_addresses#1"], "uuid": "UUID#1"}, {"computer_fqdn": "computer_fqdn#2", "mac_addresses": ["mac_addresses#2"], "uuid": "UUID#2"}], "success": true, "request_time": null}

6.3.15. /api/v3/hosts_delete

"""Remove one or several hosts from the WAPT Server database and optionnally the host packages

Args:
    uuids (list): list of uuids to delete
    filter (csvlist of field:regular expression): filter based on attributes
    delete_packages (bool): delete host's packages
    delete_inventory (bool): delete host's inventory

Returns:
    result (dict):
"""

If you want to delete a host from the inventory:

curl --cert "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt" --key "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem" --insecure -X POST --data-raw '{"uuids":["UUID"],"delete_inventory":"True","delete_packages":"True"}' -H "Content-Type: application/json" "https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v3/hosts_delete"

{"msg": "1 files removed from host repository\n1 hosts removed from DB", "result": {"files": ["/var/www/wapt-host/UUID.wapt"], "records": [{"computer_fqdn": "computer_fqdn", "uuid": "UUID"}]}, "success": true, "request_time": null}

If you do not want to delete from the inventory:

curl --cert "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt" --key "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem" --insecure -X POST --data-raw '{"uuids":["UUID"],"delete_inventory":"False","delete_packages":"False"}' -H "Content-Type: application/json" "https://admin:MYPASSWORD@srvwapt.mydomain.lan/api/v3/hosts_delete"

{"msg": "0 files removed from host repository\n1 hosts removed from DB", "result": {"files": [], "records": [{"computer_fqdn": "computer_fqdn", "uuid": "UUID"}]}, "success": true, "request_time": null}

6.3.16. /api/v3/trigger_host_action

Todo

Tests

6.3.17. /api/v3/upload_waptsetup

# Upload waptsetup

#Handle the upload of customized waptagent.exe into wapt repository

### DOES NOT WORK
#curl --cert "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.crt" --key "C:\Program Files (x86)\wapt\private\71253c6c-f412-455b-a907-93b10ce07490.pem" --insecure -X POST -H "Content-Type: multipart/form-data" -F 'data=@waptagent.exe' "https://admin:MYPASSWORD@srvwapt.mydomain.lan/upload_waptsetup"

6.3.18. /api/v3/ping

Ping shows a general set of informations on a WAPT Server.

# https://srvwapt.mydomain.lan/ping
# Lists WAPT Server informations

ping_wapt = wgets('https://%s:%s@%s/ping' % (wapt_user,wapt_password,wapt_url))
parsed = json.loads(ping_wapt)
print(json.dumps(parsed, indent=1, sort_keys=True))
